Aggregate & Rock Testing Equipment Large Sample Splitter Machine

Category :Aggregate & Rock
Name :
Tel :
Email :
Content :


Product Description:

Sample Splitter very sturdily constructed with cadmium coated plated for rust protection. It is designed for the reduction of test sample which are too large in volume. It handles any material from size up to 108 mm. Each chute bar is 1/2" wide. The opening start from 1/2", 1", 1 1/2", 2", 3" & 4" are possible.

Technical Parameters:

Material steel, thickness 2.5mm
Standard ASTM C702, EN 9221, UNI 8520
Chute Bar  Width 12.7mm
Chute Bar qty 48PCS
Width from 1/2", 1", 1 1/2", 2", 3" & 4" are possible.
Collecting Pan 2nos
Weight about 60KG
Dimension 460 (L) x 723 (W) x 958 (H) mm
