Technical Specifications:
OBRK-10 | OBRK-30 | |
10KN | 30KN | |
Sample dimension | Ф39.1×80 mm | Ф39.1×80 mm, Ф61.8×125 mm |
Strain rate | 0.016-1.6mm/min. six-speed mechanical transmission | 0.0024-4.5mm/min. 16-speed mechanical transmission |
Table stroke | Max. 50mm | Max. 90mm |
Confining pressure | 0-2Mpa | 0-2Mpa |
Back pressure | 0-1.0Mpa | 0-1.0Mpa |
Volume change | 0-50ml/0.1ml | 0-50ml/0.1ml |
Hole pressure | 0-2Mpa | 0-2Mpa |
Axial displacement | 0-30mm | 0-30mm |
Power | 220V±10% | 220V±10% |
Machine dimension | 350x300x1100mm (LxWxH) | 500x430x1200mm (LxWxH) |
Controller Dimension | 500x500x925mm (LxWxH) | 500x500x925mm (LxWxH) |
Weight | 170KG | 180KG |
